StarTech.com SDI to HDMI Converter – 3G SDI to HDMI Adapter with SDI Loop Through Output
Description
The SDI2HD 3G SDI to HDMI converter enables you to turn a 3G SDI video signal into an HDMI video output. The adapter features a built-in 3G SDI daisy chain port, giving you the ability to further extend the SDI source to up to 755ft (230m) over standard coaxial cable, for large scale HD-SDI video broadcasting distribution.
To ensure you maintain perfect high-definition video quality the SDI-HDMI converter features supports resolutions up to 1080p, allowing you to convert SDI to HDMI without sacrificing video quality.
For hassle-free installation, the SDI to HDMI converter offers a plug-and-play solution that includes pre-installed mounting brackets and requires no software or driver installation.
The SDI2HD is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Increase scalability, with built-in 3G SDI daisy chain port
- Maintain High-definition video quality while converting from 3G SDI to HDMI, with support for resolutions up to 1080p
- Hassle-free installation, with pre-installed mounting brackets and no software or drivers required
| Ports & interfaces | |
|---|---|
| Connector 2 | 2xSDI(BNC) |
| Connector 1 | HDMI |
| Technical details | |
| Output current | 2000 mA |
| Output voltage | 5 V |
| Maximum resolution | 1920 x 1080 pixels |
| Input voltage | 100 - 240 V |
| Product colour | Black |
| AC adapter included | Yes |
| Design | |
| RoHS compliance | Yes |
| Product colour | Black |
| Performance | |
| RoHS compliance | Yes |
| Output current | 2000 mA |
| Output voltage | 5 V |
| Maximum resolution | 1920 x 1080 pixels |
| Input voltage | 100 - 240 V |
| Product colour | Black |
| Data transfer rate | 1.485 Gbit/s |
| Power | |
| Output current | 2000 mA |
| Output voltage | 5 V |
| Input voltage | 100 - 240 V |
| Operational conditions | |
| Storage temperature (T-T) | -10 - 60 °C |
| Relative humidity | 5 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
| Width | 100 mm |
| Weight | 202 g |
| Height | 25 mm |
| Depth | 70 mm |
| Packaging data | |
| Package width | 215 mm |
| Package height | 52 mm |
| Package depth | 152 mm |
| Package weight | 492 g |
| Packaging content | |
| AC adapter included | Yes |
| Quantity per pack | 1 pc(s) |
Specifications
UNSPSC Code
26121630
Brand
StarTech.com
Categories
Computer, AV & Power Cables
Category
Video Cable Adapters
Connector 1
HDMI
Connector 2
2 x BNC
