StarTech.com Mini DisplayPort to HDMI 4K Audio / Video Converter – mDP 1.2 to HDMI Active Adapter for Mac Book Pro / Mac Book Air – 4K @ 30 Hz - White
Description
The MDP2HD4KSW Mini DisplayPort to HDMI adapter enables you to connect devices such as the MacBook Pro, MacBook Air and any Microsoft Surface Pro devices with mDP, to an HDMI display. This adapter is compatible with Mini DisplayPort 1.2 & HDMI 4K @ 30 Hz and as a result can support video resolutions up to Ultra HD (4K) as well as the accompanying digital audio up to 7.1 channel surround sound.
With support for Ultra HD (4K) the mDP to HDMI adapter ensures you can convert Mini DisplayPort to HDMI while maintaining an astonishing picture quality four times the resolution of high-definition 1080p. The adapter is also backward compatible with previous DisplayPort revisions 1.0/1.1 with support for resolutions up to 1080p.
For a hassle-free setup the Mini DisplayPort to HDMI adapter allows for plug-and-play installation without any additional software or drivers. Plus, with a small footprint and lightweight design, the adapter maximizes portability.
To ensure compatibility with any Mini DisplayPort output the mDP adapter offers an active conversion. Active video conversion is required to maintain 4K resolutions when converting Mini DisplayPort to HDMI. An active mDP adapter is also ideal for outputting 1080p resolutions by ensuring compatibility with graphics cards that are not capable of outputting multi-mode DP++ signals (e.g. ATI Eyefinity).
To support your Mac the HDMI converter is compatible with Intel Thunderbolt devices that output a DisplayPort video signal.
With a sleek uniform white design the MDP2HD4KSW looks great next to your Mac, and is backed by a 3-year StarTech.com warranty, and lifetime technical support.
The StarTech.com Advantage
- Prepare for the next generation of displays, with support for Ultra HD 4K video
- Maximize compatibility, with support for DisplayPort revisions 1.2/1.1/1.0
- Easy to carry as a laptop accessory, with a compact design and no external power adapter needed
| Features | |
|---|---|
| Converter type | Active |
| HDMI version | 1.4 |
| DisplayPort version | 1.2 |
| Product colour | White |
| Cable length | 0.15 m |
| Connector 1 | Mini DisplayPort |
| Connector 2 | HDMI |
| Connector 1 gender | Male |
| Connector 2 gender | Female |
| Maximum resolution | 3840 x 2160 pixels |
| Supported graphics resolutions | 1280 x 720 (HD 720),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),3840 x 2160 |
| Supported video modes | 720p,1080p,2160p |
| HDCP | Yes |
| Plug and Play | Yes |
| RoHS compliance | Yes |
| Certification | CE, FCC, REACH |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| DisplayPort Content Protection (DPCP) | Yes |
| Supported audio channels | 7.1 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Technical details | |
| Compatible products | Mac Book Pro / Mac Book Air |
| Packaging data | |
| Package width | 103 mm |
| Package depth | 188 mm |
| Package height | 13 mm |
| Package weight | 22 g |
| Quantity per pack | 1 pc(s) |
| Other features | |
| Compatible products | Mac Book Pro / Mac Book Air |
| Weight & dimensions | |
| Weight | 16 g |
| Package width | 103 mm |
| Package depth | 188 mm |
| Package height | 13 mm |
| Package weight | 22 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
Specifications
UNSPSC Code
43202222
Brand
StarTech
Categories
Computer, AV & Power Cables
Category
Video Cable Adapters
Connector 1
Mini DisplayPort
Connector 1 gender
Male connector
Connector 2
HDMI
Connector 2 gender
Female connector
