StarTech.com Laptop Docking Module for Conference Table Connectivity Box
Description
Add docking station capabilities to a boardroom, classroom or huddle space. This laptop docking module for the StarTech.com conference table connectivity box lets you:
Access your room's display and peripherals
Charge mobile devices using the USB-A charge port
Power a supported USB-C laptop with USB Power Delivery
Dock Your Laptop
Modern office environments need to support technology more than ever, to keep laptops, phones and tablets connected. During meetings, you may need to set up video conference calls using applications such as Skype for Business or Zoom.
Connect a USB-C or USB-A laptop to the module and access your room's peripherals, webcams, speakers, mics, network and HDMI display. The boardroom docking station module lets you collaborate with others in the room and around the globe.
For users that are unable to dock or for quick access to the display, the front-facing HDMI port lets you connect a laptop directly to the display.
Customizable
Architectural connectivity is becoming the trend when designing a boardroom or huddle space. StarTech.com docking station modules let you:
Customize laptop docking according to the specific needs of your space
Install in easy-to-access locations
You can install this module as a standalone solution using the supplied table-mounting bracket, or as an addition to a StarTech.com single-module (BEZ4MOD) or dual-module (BOX4MODULE) conference room table connectivity box (each sold separately).
MOD4DOCKACPD is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Easily access boardroom or huddle space devices and set up conference calls using applications such as Skype for Business
- Connect to all your boardroom peripherals from a USB-C or USB-A laptop
- Power and charge your USB-C laptop with USB Power Delivery 2.0 (up to 60W)
| Ports & interfaces | |
|---|---|
| Combo headphone/mic port | No |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Headphone connectivity | 3.5 mm |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
| HDMI ports quantity | 3 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Connectivity technology | Wired |
| Network | |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Networking standards | IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Ethernet LAN | Yes |
| Performance | |
| UASP support | Yes |
| Maximum digital resolution | 3840 x 2160 pixels |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Product colour | Black |
| Card reader integrated | No |
| LED indicators | Power |
| Data transfer rate | 5 Gbit/s |
| Certification | CE, FCC, TAA, REACH |
| Housing material | Aluminium, Plastic |
| Technical details | |
| Product colour | Black |
| Data transfer rate | 5 Gbit/s |
| Sustainability certificates | RoHS |
| Quantity per master (outer) case | 4 pc(s) |
| Master (outer) case width | 27.3 cm |
| Master (outer) case length | 43 cm |
| Master (outer) case height | 24.6 cm |
| Storage | |
| Card reader integrated | No |
| Power | |
| Input current | 2 A |
| Power plug type | Type N |
| Compatible power plug types | EU,UK,US |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 60 W |
| Output voltage | 20 V |
| Output current | 6 A |
| Software | |
| Windows operating systems supported | Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64 |
| Mac operating systems supported | Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.14 Mojave,Mac OS X 10.15 Catalina,Mac OS X 10.9 Mavericks |
| Other operating systems supported | Chrome |
| Indication | |
| LED indicators | Power |
| Weight & dimensions | |
| Weight | 588 g |
| Width | 94 mm |
| Depth | 12 mm |
| Height | 61 mm |
| Package weight | 2.1 kg |
| Package width | 211 mm |
| Package depth | 251 mm |
| Package height | 10 mm |
| Design | |
| Windows operating systems supported | Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64 |
| Mac operating systems supported | Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.14 Mojave,Mac OS X 10.15 Catalina,Mac OS X 10.9 Mavericks |
| Product colour | Black |
| LED indicators | Power |
| Certification | CE, FCC, TAA, REACH |
| Packaging data | |
| Package weight | 2.1 kg |
| Package width | 211 mm |
| Package depth | 251 mm |
| Package height | 10 mm |
| Packaging content | |
| Quick start guide | Yes |
| Cables included | USB Type-A to USB Type-B, USB Type-C to USB Type-C |
| AC adapter included | Yes |
| Mounting brackets included | Yes |
| Number of screws | 12 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 65 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Certificates | |
| Certification | CE, FCC, TAA, REACH |
| Logistics data | |
| Quantity per master (outer) case | 4 pc(s) |
| Master (outer) case width | 27.3 cm |
| Master (outer) case length | 43 cm |
| Master (outer) case height | 24.6 cm |
| Other features | |
| Chipset | DisplayLink - DL-6950, Genesys Logic - GL850G, Texas Instruments - TPS65982, Parade Technologies - PS176, VIA Labs - VL813, Realtek - RTL8153 |
