StarTech.com Extreme Networks 10050 Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 1GE Gigabit Ethernet SFP - RJ-45 100m
Description
The 10050-ST is an Extreme Networks 10050 compatible copper transceiver module that has been designed, programmed and tested to work with Extreme Networks brand switches and routers. It delivers dependable 1 GbE connectivity over copper cable, for 1000Base-T compliant networks, with a maximum distance of up to 100 m (328 ft).
Technical Specifications:
Maximum Data Transfer Rate: 1000 Mbps (1 Gbps)
Type: Copper
Connection Type: RJ-45
Maximum Transfer Distance: 100 m (328 ft)
MTBF: 510,469,759 hours
Power Consumption: Low power consumption
Digital Diagnostics Monitoring (DDM): No
This SFP copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
The StarTech.com Advantage
- 100% EXTREME NETWORKS 10050 COMPATIBLE SFP TRANSCEIVER: Designed, programmed and tested to work with compatible Extreme Networks switches and routers to deliver dependable 1GbE connectivity
- TECHNICAL SPECS: 1000BASE-T
- 1Gbps
| Network | |
|---|---|
| SFP transceiver type | Copper |
| Maximum data transfer rate | 1250 Mbit/s |
| Interface type | SFP |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Technical details | |
| Package width | 90 mm |
| Package height | 31 mm |
| Maximum transfer distance | 100 m |
| Duplex system | Full |
| Compatible products | 10050 |
| Ethernet LAN | Yes |
| Performance | |
| Product colour | Silver |
| Compatible products | 10050 |
| Mean time between failures (MTBF) | 510469759 h |
| Brand compatibility | Extreme Networks |
| SFP transceiver type | Copper |
| Ethernet LAN | Yes |
| Digital Diagnostics Monitoring (DDM) | No |
| Maximum transfer distance | 100 m |
| Duplex system | Full |
| Maximum data transfer rate | 1250 Mbit/s |
| Interface type | SFP |
| Single-mode fiber (SMF) supported | No |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Copper ethernet cabling technology | 10BASE-T,100BASE-T,1000BASE-TX |
| Features | |
| Product colour | Silver |
| Certification | CE, FCC, UR, REACH |
| Compatible products | 10050 |
| RoHS compliance | Yes |
| Mean time between failures (MTBF) | 510469759 h |
| Brand compatibility | Extreme Networks |
| Weight & dimensions | |
| Width | 68 mm |
| Depth | 13.7 mm |
| Height | 13.8 mm |
| Weight | 15 g |
| Package depth | 115 mm |
| Package width | 90 mm |
| Package height | 31 mm |
| Package weight | 50 g |
| Packaging data | |
| Package depth | 115 mm |
| Number of products included | 1 pc(s) |
| Package width | 90 mm |
| Package height | 31 mm |
| Package weight | 50 g |
| Certificates | |
| Certification | CE, FCC, UR, REACH |
| RoHS compliance | Yes |
| Packaging content | |
| Number of products included | 1 pc(s) |
| Logistics data | |
| Master (outer) case width | 9 cm |
| Master (outer) case length | 11.5 cm |
| Master (outer) case height | 3.1 cm |
| Quantity per master (outer) case | 1 pc(s) |
Specifications
UNSPSC Code
43201553
Brand
StarTech.com
Categories
Networking
Category
Network Transceiver Modules
Interface type
SFP
Maximum Data Transfer Rate
1250 Mbit/s
SFP transceiver type
Copper
