Elo Touch Solution 1302L 33.8 cm (13.3") 1920 x 1080 pixels White Multi-touch Multi-user
Description
| Display | |
|---|---|
| Display number of colours | 16.78 million colours |
| Display technology | LCD |
| Viewable size, vertical | 16.5 cm |
| Viewable size, horizontal | 29.4 cm |
| Viewing angle, vertical | 170° |
| Viewing angle, horizontal | 170° |
| Touchscreen technology | Projected capacitive system |
| Supported graphics resolutions | 640 x 480 (VGA),800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 800 (WXGA),1280 x 960,1360 x 768 (WXGA),1366 x 768,1440 x 900 (WXGA+),1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080) |
| Horizontal scan range | 30 - 75 kHz |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal | 33.8 cm (13.3") |
| Contrast ratio (typical) | 800:1 |
| Display brightness | 270 cd/m² |
| Response time | 25 ms |
| Native aspect ratio | 16:9 |
| Panel type | TFT |
| HD type | Full HD |
| Design | |
| International Protection (IP) code | IPX1 |
| Product colour | White |
| Certification | Australia RCM Canada cUL, IC China CCC Europe CE Japan VCCI Korea KCC Mexico NOM Taiwan BSMI United States UL, FCC International CB RoHS, China RoHS, WEEE, REACH Russia EAC |
| Performance | |
| Touch technology | Multi-touch |
| Number of simultaneous touchpoints | 10 |
| Built-in camera | No |
| Number of speakers | 2 |
| Touchscreen type | Multi-user |
| Touchscreen technology | Projected capacitive system |
| RMS rated power | 2 W |
| On Screen Display (OSD) | Yes |
| Mean time between failures (MTBF) | 50000 h |
| Built-in speaker(s) | Yes |
| Ports & interfaces | |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| Cables included | AC, HDMI, USB |
| Audio input | 1 |
| HDMI | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB Touch port | Yes |
| USB Touch ports quantity | 1 |
| HDMI version | 1.3 |
| Ergonomics | |
| VESA mounting | Yes |
| Wall mountable | Yes |
| Panel mounting interface | 75 x 75 mm |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 / 60 Hz |
| AC adapter output voltage | 12 V |
| Power consumption (off) | 0.18 W |
| Power supply type | AC |
| Power consumption (typical) | 9.8 W |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Technical details | |
| Height (with stand) | 259.6 mm |
| Depth (with stand) | 150 mm |
| Touchscreen type | Multi-user |
| Power supply type | AC |
| Supported graphics resolutions | 640 x 480 (VGA),800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 800 (WXGA),1280 x 960,1360 x 768 (WXGA),1366 x 768,1440 x 900 (WXGA+),1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080) |
| Package weight | 2.89 kg |
| On Screen Display (OSD) | Yes |
| Sustainability certificates | RoHS |
| Audio | |
| RMS rated power | 2 W |
| Built-in speaker(s) | Yes |
| Endurance | |
| Mean time between failures (MTBF) | 50000 h |
| Colour | |
| Product colour | White |
| Certificates | |
| Certification | Australia RCM Canada cUL, IC China CCC Europe CE Japan VCCI Korea KCC Mexico NOM Taiwan BSMI United States UL, FCC International CB RoHS, China RoHS, WEEE, REACH Russia EAC |
| Weight & dimensions | |
| Width | 326.1 mm |
| Height (with stand) | 259.6 mm |
| Height | 211.3 mm |
| Depth (with stand) | 150 mm |
| Depth | 25.1 mm |
| Weight | 1.22 kg |
| Width (with stand) | 326.1 mm |
| Weight (with stand) | 2.32 kg |
| Packaging data | |
| Package width | 405 mm |
| Package depth | 160 mm |
| Package height | 280 mm |
| Package weight | 2.89 kg |
| Packaging content | |
| Cables included | AC, HDMI, USB |
| Other features | |
| Height (with stand) | 259.6 mm |
| Depth (with stand) | 150 mm |
| On Screen Display (OSD) | Yes |
