CUSTOM KBR2D-C Barcode module bar barcode readers 1D/2D Black
Description
| Scanning | |
|---|---|
| Type | Barcode module bar barcode readers |
| Linear (1D) barcodes supported | Codabar,Code 93,EAN-13,EAN-8,GS1 DataBar Expanded,GS1 DataBar Omnidirectional,GS1 Databar Limited,Industrial 2 of 5,Interleaved 2 of 5,JAN,MSI,Matrix 2 of 5,Plessey,UPC-A,UPC-E |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, Han Xin, Micro QR Code, MicroPDF417, PDF417, QR Code |
| Working distance | 28 cm |
| Scanner type | 1D/2D |
| Pitch reading angle | 5 - 60° |
| Light levels (direct sunlight) | 0 - 100000 lx |
| Optical sensor resolution (W x H) | 1280 x 800 pixels |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Standard interfaces | USB |
| Performance | |
| Housing material | Polycarbonate (PC) |
| Built-in display | No |
| Product colour | Black |
| Buzzer | Yes |
| Light levels (direct sunlight) | 0 - 100000 lx |
| Design | |
| Type | Barcode module bar barcode readers |
| Housing material | Polycarbonate (PC) |
| Product colour | Black |
| Power | |
| Power consumption | 380 mA |
| Power source type | DC |
| Input voltage | 5 V |
| Weight & dimensions | |
| Width | 56 mm |
| Depth | 69 mm |
| Height | 28 mm |
| Weight | 106 g |
| Technical details | |
| Type | Barcode module bar barcode readers |
| Housing material | Polycarbonate (PC) |
| Built-in display | No |
| Product colour | Black |
| Buzzer | Yes |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 20 - 95% |
| Light levels (direct sunlight) | 0 - 100000 lx |
Specifications
UNSPSC Code
43211701
Brand
Own Brand
Categories
Printers & Scanners
Category
Barcode Scanner
Connectivity technology
Wired
Power source type
DC
Product Colour
Black
Scanner type
1D/2D
Standard interfaces
USB
Type
Barcode module bar barcode readers
