Description
| Power | |
|---|---|
| Output power | 600 W |
| Input operation voltage (min) | 170 V |
| Input operation voltage (max) | 300 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 680 J |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Output power capacity | 1000 VA |
| Ports & interfaces | |
| Cable length | 2.44 m |
| USB port | Yes |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| SmartSlot | Yes |
| AC outlets quantity | 4 AC outlet(s) |
| AC outlet types | C13 coupler |
| Power plug | C14 coupler |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Number of outlets (Battery backup & protection) | 4 |
| Performance | |
| Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
| UPS topology | Line-Interactive |
| Waveform | Sine |
| Automatic Voltage Regulation (AVR) | Yes |
| Surge protection | Yes |
| Noise level | 41 dB |
| Audible alarm(s) | Yes |
| Features | |
| Output frequency | 50/60 Hz |
| Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
| UPS topology | Line-Interactive |
| Waveform | Sine |
| Automatic Voltage Regulation (AVR) | Yes |
| Output power | 600 W |
| Input operation voltage (min) | 170 V |
| Input operation voltage (max) | 300 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 680 J |
| Surge protection | Yes |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Noise level | 41 dB |
| Audible alarm(s) | Yes |
| Output power capacity | 1000 VA |
| Input frequency | 50/60 Hz |
| Battery | |
| Battery life (max) | 6 year(s) |
| Number of batteries supported | 1 |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 3 h |
| Replacement battery cartridge | APCRBC124 |
| Design | |
| Rack capacity | 2U |
| Form factor | Rackmount |
| Product colour | Black |
| Display | LCD |
| Certification | CSA, CSA C22.2 No. 107.1, FCC Part 15 Class B, ICES-003, UL 1778, REACH |
| Cable length | 2.44 m |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
| Technical details | |
| Output frequency | 50/60 Hz |
| Sustainability certificates | RoHS, ENERGY STAR |
| Weight & dimensions | |
| Weight | 20.5 kg |
| Width | 432 mm |
| Height | 86 mm |
| Depth | 406 mm |
| Package width | 535 mm |
| Package depth | 570 mm |
| Package height | 235 mm |
| Package weight | 20.7 kg |
| Packaging data | |
| Cables included | RJ-45,RS-232 |
| Resource CD | Yes |
| Rack mount kit | Yes |
| Software CD | Yes |
| Package width | 535 mm |
| Package depth | 570 mm |
| Package height | 235 mm |
| Package weight | 20.7 kg |
| Logistics data | |
| Quantity per pallet | 16 pc(s) |
| Certificates | |
| Certification | CSA, CSA C22.2 No. 107.1, FCC Part 15 Class B, ICES-003, UL 1778, REACH |
| Packaging content | |
| Cables included | RJ-45,RS-232 |
| Resource CD | Yes |
| Rack mount kit | Yes |
| Software CD | Yes |
Specifications
UNSPSC Code
39121011
Brand
APC
Categories
Batteries, Chargers & Power Supplies
Category
Uninterruptible Power Supplies (UPSs)
Form Factor
Rackmount
Output Power
500W to 1000W
Output Power Capacity
600VA to 1200VA
Product Colour
Black
UPS topology
Line-interactive
